ULTRASONIC ATOMIZATION GRANULATION
Precise, Uniform Spray for Complex Coating Applications
The UAG1000 fluid bed system for R&D applications is now available with integrated ultrasonic spray technology for superior performance in fluid bed coating, granulation, drying, and spray drying.
Ultrasonic atomization creates a fine mist of extremely small droplets capable of coating small granules or even powders in a fluid bed process. Cheersonic enables the ultrasonic nozzle to operate in the higher temperatures of a fluid bed system while conveying the coating material in an upward direction towards the fluidized product.
The ultrasonic system delivers consistently-sized droplets across a wide flow range from 500 uL/min to 10 mL/min. The lack of high pressure atomizing air eliminates disturbances to fluidization that can occur with air-atomized nozzles.
APPLICABLE INDUSTRIES
PERFECTING YOUR PROCESS
Faster Granulation
The conical shape of the expansion chamber reduces the velocity of the air in the filter chamber by 50%. The reduction in velocity helps to keep the smaller or fine particles out of the upper filter region and below the spray nozzles when granulating. A secondary benefit is a reduction in the total height of the expansion chamber.
Ultrasonic Technology
This systems are designed to maintain critical scale-up factors from one unit to the next. Starting with our Model 50 to our largest available units, each system operates with nearly identical bed depths, air velocities, and air ratios (quantity of air per cubic foot of product), greatly simplifying the scale up of product from one unit to the next.
OUR EXPERTISES
Cheersonic offers innovative and customized solutions that will meet your needs. Discover how our expertise, combined to yours, can speed up your production.
